REF : AB0282DA
HYDRAULIC BREAKER AB0282DA
This equipment is no longer available for sale. We invite you to check the available spare parts listed below or contact our sales department at +33 3 24 33 64 32 or by email at commerce@arden-equipment.com.
Description
This equipment is no longer available for sale. We invite you to check the available spare parts listed below or contact our sales department at +33 3 24 33 64 32 or by email at commerce@arden-equipment.com.
More Information
| Specification | Details |
|---|---|
| SKU | AB0282DA |
| Professions | Demolition, Earthmoving, Landscaping |
| Working pressure (psi) | 2611 |
| Flow min (gal/min) | 8 |
| Maximum flow rate (gal/min) | 11 |
| Weight (lbs) | 493.92 |
Spare Parts
Please note that these PRs are associated with the latest model currently in production.
Thank you for checking your equipment with the configurator by entering your serial number.
See the configurator| N° | Name | Reference | Actions |
|---|---|---|---|
| Spare part | |||
| Bloc central | PRBB032V-11102 |
|
|
| RACCORD | PRBB008-11800 |
|
|
| BOUCHON | PRBB008-11900 |
|
|
| BOUCHON | PRB004012-10200 |
|
|
| BOUCHON | PRB004012-10400 |
|
|
| PISTON | PRBB031V-11200 |
|
|
| BAGUE BLOC CENTRAL | PRBB031V-11300 |
|
|
| NEZ MARTEAU | PRBB031V-12102 |
|
|
| FRONT COVER | PRBB030-12300 |
|
|
| Pin | PRBB030-12650 | ||
| Rubber plug | PRBB030-12620 | ||
| GRAISSEUR | PRB004013-10400 |
|
|
| RETAINER PIN | PRBB030-12600 | ||
| Pin | PRBB030-12610 | ||
| Spring | PRBB008-12630 | ||
| GOUPILLE | PRBB030-12640 |
|
|
| BOUCHON | PRBB050-12111 |
|
|
| CHAMBRE ARRIÈRE | PRBB031V-13100 |
|
|
| COUVERCLE D'ACCUMULATEUR | PRBB042V-14200 |
|
|
| CORPS D'ACCUMULATEUR | PRBB042V-14100 |
|
|
| Diaphragm | PRBB062V-14300 | ||
| RONDELLE | PRB002008-18000 |
|
|
| Socket bolt | PRB002002-18080 |
|
|
| VIS | PRB002002-12035 |
|
|
| MOIL POINT | PRBB030-12510 | ||
| CHISEL POINT | PRBB030-12520 | ||
| POINTE PILON | PRBB030-12540 | ||
| POINTE BECHE HORIZONTALE | PRBB030-2992H |
|
|
| NPU HA -POINTE BECHE VERTICALE | PRBB030-2992V |
|
|
| KIT VALVE AZOTE | PRBB008-13200 |
|
|
| KIT VALVE REGLAGE COMPLET | PRBB030-11456 |
|
|
| KIT TIRANT | PRBB031V-12200 |
|
|
| KIT ACCUMULATEUR | PRBB032V-14001 |
|
|
| Seal Kit | PRBB032V-SK003 | ||
| SOUPAPE | PRBB062V-14400 |
|
|
| Manteau de marteau | PRBB032V-55000 |
|
|
| AMORTISSEUR INFERIEUR | PRBB032V-35100 |
|
|
| AMORTISSEUR SUPERIEUR | PRBB030V-35200 |
|
|
| Plat de maintien | PRBB030V-35400 |
|
|
| Vis à tête hexagonale | PRB002001-20060 |
|
|
| Ecrou hexagonal | PRB002003-2000N |
|
|
| RONDELLE GUIDE (NYLON) | PRBB050V-27219 |
|
|
| PLAQUE GUIDE (NYLON) | PRBB020V-35500B |
|
|
| Joint O-Ring | PRB007001-180P |
|
|
| PLAQUE GUIDE (NYLON) | PRBB020V-35600F |
|
|
| CAISSON DE TÊTE | PRBB032V-55024 |
|
|
| AMORTISSEUR | PRBB070V-27110 |
|
|
| BOUCHON | PRBB030V-12800 |
|
|
| RUBBER COVER AB0282 | PRBB020V-12700 |
|
|
| COUVERCLE | PRBB008V-27129 |
|
|
| COUVERCLE VISSE AB0282 | PRBB032V-27119 |
|
|
| Vis à tête cylindrique à 6 pans creux | PRB002002-10030 |
|
|
| Vis à tête hexagonale | PRB002001-10030 |
|
|
| RONDELLE | PRB002008-10000 |
|
